Oil & Fuel Delivery Hose

Description

Our Oil & Fuel Delivery Hose is engineered for reliability in oil and fuel applications.
Designed with superior materials, it offers excellent resistance to abrasion, weather, and ozone, ensuring long-lasting performance across industrial settings.

• Tube: Oil & Fuel resistant conductive black NBR.
• Reinforcement: High-tensile synthetic cord with antistatic copper wires.
• Cover: Oil, weather and ozone resistant, smooth, cloth impression black CR.
• Temperature Range: -30°C to +70°C (-22°F to +158°F)
• Remarks: Upon request also available with 4:1 safety factor for offshore industry.

code	inch	mm	mm	bar	psi	bar	psi	gr/mt	mm	mt
MO-010-019-V	3/4	19	30	10	150	30	450	550	160	20-40
MO-010-025-V	1	25	36	10	150	30	450	650	200	20-40
MO-010-032-V	1 1/4	32	43	10	150	30	450	830	255	20-40
MO-010-038-V	1 1/2	38	49	10	150	30	450	980	300	20-40
MO-010-051-V	2	51	63	10	150	30	450	1400	410	20-40
MO-010-063-V	2 1/2	63	76	10	150	30	450	1830	500	20-40
MO-010-076-V	3	76	90	10	150	30	450	2400	600	20-40
MO-010-102-V	4	102	118	10	150	30	450	3700	800	20-40
MO-010-127-V	5	127	143	10	150	30	450	4300	1000	20-40
MO-010-152-V	6	152	168	10	150	30	450	5000	1200	20-40
