OIL & FUEL SUCTION AND DELIVERY HOSE 10 BAR (150 PSI)

Description

OIL & FUEL SUCTION AND DELIVERY HOSE 10 BAR (150 PSI)

Our Oil & Fuel Suction and Delivery Hose is engineered for reliability in oil and fuel applications.
Designed with superior materials, it offers excellent resistance to abrasion, weather, and ozone, ensuring long-lasting performance across industrial settings.

• Tube: Oil & Fuel resistant conductive black NBR.
• Reinforcement: High-tensile synthetic cord with steel wire helix and antistatic copper wires.
• Cover: Oil, weather and ozone resistant, smooth, cloth impression black NBR.
• Temperature Range: -30°C to +70°C (-22°F to +158°F)
• Remarks: Upon request also available with 4:1 safety factor for offshore industry.

Applications:

• Ideal for use suction and discharge of petroleum products with aromatic content up to %50

code	inch	mm	mm	bar	psi	bar	psi	gr/mt	mm	mt
MO-010-019-A	3/4	19	29	10	150	30	450	550	100	20-40
MO-010-025-A	1	25	35	10	150	30	450	650	150	20-40
MO-010-032-A	1 1/4	32	42	10	150	30	450	900	190	20-40
MO-010-038-A	1 1/2	38	49	10	150	30	450	1025	230	20-40
MO-010-051-A	2	51	63	10	150	30	450	1590	300	20-40
MO-010-063-A	2 1/2	63	75	10	150	30	450	1900	380	20-40
MO-010-076-A	3	76	90	10	150	30	450	2600	460	20-40
MO-010-102-A	4	102	118	10	150	30	450	4250	600	20-40
MO-010-127-A	5	127	145	10	150	30	450	5900	750	20-40
MO-010-152-A	6	152	172	10	150	30	450	7250	900	20-40
MO-010-203-A	8	203	225	10	150	30	450	12500	1300	20
