OIL & FUEL SUCTION AND DELIVERY HOSE 20 BAR (300 PSI)

Description

OIL & FUEL SUCTION AND DELIVERY HOSE 20 BAR (300 PSI)

Our OIL/SD/3 Hose is engineered for reliability in oil and fuel applications.
Designed with superior materials, it offers excellent resistance to abrasion, weather, and ozone, ensuring long-lasting performance across industrial settings.

• Tube: Oil & Fuel resistant conductive black NBR.
• Reinforcement: High-tensile synthetic cord with steel wire helix and antistatic copper wire.
• Cover: Oil, weather and ozone resistant, smooth, cloth impression black NBR.
• Temperature Range: -30°C to +70°C (-22°F to +158°F)
• Remarks: Upon request also available with 4:1 safety factor for offshore industry.

Applications:

• Ideal for use high pressure of suction and discharge of petroleum products with aromatic content up to %50

code	inch	mm	mm	bar	psi	bar	psi	gr/mt	mm	mt
MO-020-019-A	3/4	19	31	20	300	60	900	725	125	40
MO-020-025-A	1	25	37	20	300	60	900	840	150	40
MO-020-032-A	1 1/4	32	44	20	300	60	900	1100	190	40
MO-020-038-A	1 1/2	38	51	20	300	60	900	1350	230	40
MO-020-051-A	2	51	65	20	300	60	900	1850	300	40
MO-020-063-A	2 1/2	63	79	20	300	60	900	2750	380	40
MO-020-076-A	3	76	92	20	300	60	900	3400	460	40
MO-020-102-A	4	102	119	20	300	60	900	4700	600	40
MO-020-127-A	5	127	145	20	300	60	900	7300	750	40
MO-020-152-A	6	152	174	20	300	60	900	9600	1000	40
MO-020-203-A	8	203	228	20	300	60	900	14600	1300	20
