CHEMICAL UHMPWE SUCTION AND DELIVERY HOSE 16 BAR (250 PSI)

Description

Our High Pressure UPE Chemical Suction and Delivery Hose is engineered for reliability in chemical and acids applications.

Designed with superior materials, it offers excellent resistance to abrasion, weather, and ozone, ensuring long-lasting performance across industrial settings.

• Tube: Chemical and solvent resistant translucent UHMWPE
• Reinforcement: High-tensile synthetic cord with wire helix and antistatic copper wires.
• Cover: Weather, ozone and abrasion resistant, smooth, cloth impression blue EPDM.
• Temperature Range: -30°C to +80°C (-22°F to +176°F)
• Remarks: Upon request other colours available.

Aplication:

• Used for high pressure suction and discharge of chemicals, acids and high aromatic solvents.

code	inch	mm	mm	bar	psi	bar	psi	gr/mt	mm	mt
MX-016-019-AU	3/4	19	31	16	250	51	750	630	120	40
MX-016-025-AU	1	25	37	16	250	51	750	780	150	40
MX-016-032-AU	1 1/4	32	44	16	250	51	750	1000	200	40
MX-016-038-AU	1 1/2	38	51	16	250	51	750	1250	230	40
MX-016-051-AU	2	51	67	16	250	51	750	1830	300	40
MX-016-063-AU	2 1/2	63	79	16	250	51	750	2400	380	40
MX-016-076-AU	3	76	92	16	250	51	750	3000	460	40
MX-016-102-AU	4	102	118	16	250	51	750	3900	600	40
