Description
OILFIELD FRAC S/D HOSE 400 PSI
Our OILFIELD FRAC S/D Hose is engineered for reliability in fracturing oilfield applications.
Designed with superior materials, it offers excellent resistance to abrasion, weather, and ozone, ensuring long-lasting performance across industrial settings.
- Tube: Oil & Fuel resistant conductive black NBR.
- Reinforcement: High-tensile synthetic cord with wire helix antistatic copper wire.
- Cover: Oil, weather and ozone resistant, smooth, cloth impression black NBR.
- Temperature Range: -30°C to +70°C (-22°F to +158°F)
Applications:
- Premium hose for high pressure suction and discharge of crude oil for frac tank connections
 |  |  |  |  |  |  | ||||
| code | inch | mm | mm | bar | psi | bar | psi | gr/mt | mm | mt |
| MO-025-076-AF | 3 | 76 | 96 | 25 | 400 | 75 | 1200 | 3600 | 625 | 40 |
| MO-025-102-AF | 4 | 102 | 125 | 25 | 400 | 75 | 1200 | 5550 | 950 | 40 |
| MO-025-127-AF | 5 | 127 | 153 | 25 | 400 | 75 | 1200 | 7700 | 1300 | 40 |
