OILFIELD FRAC HOSE 400 PSI

Description

OILFIELD FRAC HOSE 400 PSI

Our OILFIELD FRAC  Hose is engineered for reliability in fracturing oilfield applications.
Designed with superior materials, it offers excellent resistance to abrasion, weather, and ozone, ensuring long-lasting performance across industrial settings.

• Tube: Oil & Fuel resistant conductive black NBR.
• Reinforcement: High-tensile synthetic cord with antistatic copper wire.
• Cover: Oil, weather and ozone resistant, smooth, cloth impression black NBR.
• Temperature Range: -30°C to +70°C (-22°F to +158°F)

Applications:

• Premium hose for high pressure discharge of crude oil for frac tank connections

code	inch	mm	mm	bar	psi	bar	psi	gr/mt	mm	mt
MO-025-076-VF	3	76	96	25	400	75	1200	3560	600	40
MO-025-102-VF	4	102	125	25	400	75	1200	5450	900	40
MO-025-127-VF	5	127	153	25	400	75	1200	7550	1200	40
